Whirlybird Aviation

The Finest Autogyro Plans Available



On this page you will find scratch building plans for great looking and flying model autogyros. From rotor diameters of 50 to 78 inches, they are all of built up construction, being mainly built from balsa, light ply, birch ply and piano wire. The only non standard part is the rotor blade mounting plate which is constructed from 1/16 inch G-10 fiber glass plate and is easily obtainable through your local hobby store or industrial supply company. Because of the forces involved with the rotors on direct control heads, we strongly recommend using high torque metal geared servos. We also suggest the same servo for on the rudder.

The .25 size Profile Kellett Autogyro is an easy model to make and is a profile as the title suggests. Easy to fly and is very tough!

The .25 size DAGs come in 2 versions. The original DAG R1 with it's simple but very elegant lines, is easy to build with stick construction. The DAG R2 version, which still has the pleasing lines of the original but with a rounded fuselage for a more �scale like� look using formers and stringers.

The 60 size DAG 60 is a beautiful large autogyro that floats and is graceful flying. It is the larger version of the R2 with some changes within the design.

The Pitcairn PCA-2 is a scaled down model of the famous Pitcairn PCA-2 autogyro with no controls needed on head, aileron, rudder and elevator are your controls. It is so easy to fly, you will think you are flying a trainer! A true beauty on the ground or in the air!

Basically the Choice is yours......



The Profile Kellett

@ copyright Mon Feb 28 18:05:30 UTC 2011 - All Rights Reserved



The Profile Kellett is a fun and very easy scratch build plan. This autogyro project is geared towards the beginner pilot, experience pilots will appreciate the simplicity and easy handling. Plank fuselage design will give the strength the new pilot needs. The experienced pilot will appreciate the strength for wild crazy maneuvers.

 Engine: 32-40 cu 2 stroke or 40-52 four stroke and or electric equivalent.

Rotor Span: 50 inches

Servos: Mini Servo metal geared for the Rudder

2 High torque metal geared servos for the head.



PLAN SHEET: $30.00

FREE Shipping in lower 48

Pay Pal:  whirlybirdgyros@gmail.com

Please write item desired in comment section.









xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx



The DAG R1

� copyright Mon Feb 28 17:45:59 UTC 2011 - All Rights Reserved



 The DAG-R1 was the first designed as a the next step to building and flying autogyros after mastering the Profile Kellett. The fuselage is all stick construction and is very light yet very strong airframe. The plan is full of details, illustrations and directions to make for a pleasurable build.





Engine: 32-40 cu 2 stroke or 40-52 four stroke and or electric equivalent.

Rotor Span: 50 inches

Servos: Mini Servo metal geared for the Rudder

2 High torque metal geared servos for the head.



PLAN SHEET: $30.00

FREE Shipping in lower 48

Pay Pal:  whirlybirdgyros@gmail.com

Please write item desired in comment section.







xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx



The DAG R2

� copyright Mon Feb 28 17:37:54 UTC 2011 - All Rights Reserved







The DAG R2 is the advanced brother of the DAG R1. Built up fuselage, stringers and formers really show off the curve of a true 1930's autogyro. Like the R1, this project is for the experienced scratch builder. Not a difficult build, the R2 does not disappoint to satisfy the builder pride after completion. She looks elegant.....but you can yank and crank her in the air. So much fun!



 Engine: 32-40 cu 2 stroke or 40-52 four stroke and or electric equivalent.

Rotor Span: 50 inches

Servos: Mini Servo metal geared for the Rudder

2 High torque metal geared servos for the head.



PLAN SHEET: $30.00

FREE Shipping in lower 48

Pay Pal:  whirlybirdgyros@gmail.com

Please write item desired in comment section.











xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx





The DAG 60

� copyright Mon Feb 28 17:14:08 UTC 2011 - All Rights Reserved



The DAG 60 is the BIG brother of the R2. The plan sheets are huge and are loaded with information on how to build the 60. You are going to love the size of this bird! An aircraft is such a pleasure to work on....when your hands fit in the fuselage! Those beautiful lines from the R2 explode on the DAG-60. You will smile every time you gaze upon her. The term "Bigger flies better" applies to the DAG-60 as it floats about the sky.

Rotor Span: 78 inches

Head: 2 High torque metal geared servos

1-Standard High torque  metal geared servo for the Rudder

Elevator: 1-Standard size servo

60 Two Stoke or 91 Fourstroke



2 HUGE PLAN SHEETS: $55.00 Shipped To your door

FREE Shipping in lower 48

Pay Pal:  whirlybirdgyros@gmail.com

Please write item desired in comment section.











XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX


The Pitcairn PCA 2
� copyright Mon Feb 28 16:35:07 UTC 2011 - All Rights Reserved



How about a scale autogyro, one you have seen photos of on the internet....one who is so popular on Youtube. Yes......now you can own a scale PCA-2. Our plans have been painstakingly researched, planned and designed on CAD. These are true "builder" plans with details and looks second to none. If you like to scratch build, you have found your model plan. All materials can be purchased at a local hobby shop. Regular scratch building tools are needed.

Flight characteristics are docile.....she flies like a trainers. See the video below.

Engine: .60 2 stroke to .91 four Stroke.

Rotors: 78 inches

Servos: Metal geared mini servos for ailerons

Rudder: Standard  High Torque servo

 Elevator: Standard size servo



2 HUGE PLAN SHEETS: $55.00 Shipped To your door

FREE Shipping in lower 48

Pay Pal:  whirlybirdgyros@gmail.com

Please write item desired in comment section.



PCA-2 Short Kit

2 HUGE PLAN SHEETS

All the parts that are so difficult cut by hand are laser cut

Rotors are completely finished and included

FREE Shipping in lower 48

Pay Pal:  whirlybirdgyros@gmail.com

Please write item desired in comment section.

$325.00 free shipping to the lower 48 States



Short kits are out of Stock

please check at later date.

I will post when the next bunch

will arrive. I would need at

least four Pre Orders for the

next lot. If you would like to

Pre Order, please contact me.

















Thanks for Stopping by!!!!
